General Features

• A very powerful AI CPU

• GNU compiler supported

• Python support

• Interface: USB, SPI, I2C, LAN, UART, J-TAG, ADC, GPIOs

• Support WiFi 5G/2.4GHz SoftAP, Ethernet and Contact ID modem

• Embedded BLE 5.3 with mesh capability

• Ultra low power camera module

• Support various sensors including Radar sensor

• Easy module upgradable

• Support FPGA module

• Sensor add-on easily

• Industrial operating temperature range -40°C up to +85°C (Depends on model)

• 15kV ESD protection

• Wide voltage range up to +48V

• 12~48V to 5 VDC terminal block input

• USB type C port for secondary power back up input

• DC 5V/5A power adapter jack input

• USB type C port for 5V output.

• RS232 and RS422/RS485 in separate connector.

• 2 general I/O pins.

• USB Type A host for extended capability: For ex., flash drive as recorded device

• Micro USB socket for extending I/O.

• Micro USB socket for UART TX/RX

• Micro USB socket for I2C

• Micro USB host for extended capability: For ex., flash drive as recorded device

• Secured remote upgradability

• RWLS8310 I/O expansion (Reserved)

LAN Features

Designed to meet IEEE Std. 802.3™

Supports IEEE 802.3az energy efficient Ethernet ability for 100Base-TX

in full duplex operation and 10/100Base-T in full/half duplex mode

Supports Green Ethernet

Cable length power saving

Link down Power saving

Supports link down power saving in Ethernet PHY receivers.

Ethernet port auto-crossover function.

Complete Serial-to-LAN solution with network processor, MAC (media access controller) and PHY interface.

Multiple IP Address Configuration Modes: DHCP / Static IP mode

Supports TCP/IP, ICMP, ARP, DHCP client, DNS, FTP client, POP3, SMTP, Telnet server and UDP protocols

10/100Mbps Ethernet

Web-based configuration

LED I/O to reflect LAN connection and link activity

Serial Port Features

High speed (921.6Kbps) UART

Baud rates:2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400, 460800, 921600

Parity Bits: Odd, Even, None

Data Bits: 7, 8 ~ Stop Bits: 1 or 2

Hardware (RTS/CTS) flow control

Remotely access serial port via Internet application

640/576 bytes Transmit/Receive FIFO buffer.

Support 4 port general I/O

RB8761BTV Features

Bluetooth 5.3 HS-UART interface module Supports dual mode (BR/EDR + Low Energy Controllers)

HS-UART interface for Bluetooth data transmission compliant H5 specification

Integrated MCU to execute Bluetooth protocol stack

Supports all packet types in basic rate and enhanced data rate

Supports Secure Simple Pairing

Supports multiple Low Energy states

Fast AGC control to improve receiving dynamic range

Integrated 32K oscillator for power management

Supports Power Control

Supports TX +10dBm maximum output power for Bluetooth BR/BLE

Supports TX +7.5dBm maximum output power for Bluetooth EDR

RB8762C Features

Support the Bluetooth 5.3 core specification

Frequency Range 2.402 – 2.480 GHz

Integrate MCU to execute Bluetooth protocol stack

Ultra low power consumption with intelligent PMU

Supports Master and Slave modes

Support fully multiple Low Energy states

Support LE L2CAP Connection Oriented Channel Support

Support LE low duty directed advertising

Support LE data length extension feature

Integrated Bluetooth low energy stack including ATT, GATT, SMP, L2CAP, GAP

Generic Applications for GAP Central, Peripheral, Observer and Broadcaster Roles

Support OTA (Over-the-Air) programming

Firmware upgradeable through serial port

Support internal 32KHz OSC or external 32KHz clock input for low power mode

Low power 3.3V operation

TX Power: 7.5 dBm Max ~ RX Sensitivity: -97dBm Min

Embedded 4Mbit flash

Embedded 8-CH 12-bit ADC

Support AES128/192/256 encrypt/decrypt engine

Serial Interface ( SPI / I2C / PWM)

Support 4wire SPI master/slave

Wake-up interrupt

Watch Dog Timer

On-board microprocessor, RAM and ROM

On-board antenna or on-board U.FL connector for external antenna

WiFiHU2 Features

Designed to meet IEEE 802.11a/b/g/n/ac compatible WLAN

Extended temperature available

Complete 802.11n MIMO solution for 2.4GHz and 5Ghz band

Support 802.11ac 1x1, Wave-2 compliant with MU-MIMO STA mode

Maximum PHY data rate up to 86.7Mbps using 20MHz bandwidth, 200Mbps using 40MHz bandwidth, and 433.3Mbps using 80MHz bandwidth.

Backward compatible with 802.11a/b/g devices while operating at 802.11n data rates

Backward compatible with 802.11a/n devices while operating at 802.11ac data rates.

USB 2.0 hot swappable interface

Compatible with USB2.0 host controllers

Fast receiver Automatic Gain Control (AGC)

WiFi security using WEP, WPA and WPA2

2 U.FL TX/RX antenna ports

Use carry board to support single antenna

LED output for visual monitoring of link and activity

Support Windows Win7. Win10. Win11

Support Linux

USB Features

A. Micro USB to UART TX/RX from CP2102.

B. Micro USB to I2C from 8762C.

C. Micro USB to extern I/O from raspberry pi.

D. USB Type C 5V output.

RWLS8310C-M Camera Sensor module

Contact ID alarm modem dongle

Various applications

BLE to serial ports or I/O pins

Extended USB host for USB devices plug in.

BLE host to read/write BLE devices

General I/O pins for control or input

WiFi 5G/2.4G SoftAP
